  •  HP2312AXW 12V Piezo Buzzer
 HP2312AXW 12V Piezo Buzzer

HP2312AXW 12V Piezo Buzzer

  • Product description: HP2312AXW 12V Piezo Buzzer , Low power consumption , high sound pressure, Main application of this buzzer is alarm ,Automotive alarm .
  • INQUIRY

Piezo Buzzer , Piezoelectric Buzzer HP2312XW

Buzzer Datasheet
Lead wire type
Internal Driven Piezo Buzzer (With oscillator circuit)
Dia 23x12mm Worked with 12V DC, Output3.5~ 4.5K Hz 85dB at 10cm

Type

UNIT

HP2312AXW

HP2312BXW

*Min. Sound Output at10cm

dB

85

90

Rated Voltage

VDC

12

12

Operating Voltage

VDC

3~20

3~20

Resonant Frequency

Hz

3500±500

4500±500

*Max. Current Consumption

mA

8

8

Tone Nature


Continuous

Operating Temperature

°C

-20~+70

Storage Temperature

°C

-30~+80

Weight

g

8



Value applying at rated voltag

DIMENSIONS     Unit:mm     Tolerance:±0.5
